Showing 1–20 of 252 results

cube-130/F

The cube-130/F is a 200 – 2000 mm range Microsonic “Cube” Miniature Ultrasonic Proximity Sensor, Push-Pull NO/NC output, IO-Link

cube-130/FFIU

The cube-130/FFIU is a 200 – 2000 mm range Microsonic “Cube” Miniature Ultrasonic Proximity Sensor, 2 x Push-Pull NO/NC output, 1 x analog 4-20mA / 0-10 V, IO-Link

cube-340/F

The cube-340/F is a 350 – 5000 mm range Microsonic “Cube” Miniature Ultrasonic Proximity Sensor, Push-Pull NO/NC output, IO-Link

cube-340/FFIU Microsonic “Cube” Ultrasonic Sensor, adjustable 5 position sensing head, 2 x Push-Pull outputs, 1 x analog, IO-Link

The cube-340/FFIU is a 350 – 5000 mm range Microsonic “Cube” Miniature Ultrasonic Proximity Sensor, 2 x Push-Pull NO/NC output, 1 x analog 4-20 mA / 0-10 V, IO-Link.

Features include:

  • Unique sensor head mounts in 5 different positions
  • LED display, visible in any mounting position
  • Sensing range 350 – 5000 mm
  • Analogue output: 0 – 10 V or 4-20 mA
  • Digital output: 2 x Push-Pull NO/NC
  • Resolution of 1.0 mm
  • IO-Link interface enabled
  • Smart Sensor Profiles
  • LinkControl for configuration from a PC
  • Very compact housing, only 40 mm x 40 mm x 40 mm
  • Programming by Teach-in push-buttons
  • Operating voltage 9 – 30 VDC
  • PA plastic housing with IP67 sealing and M12 – 5 pin connection

cube-35/F

The cube-35/F is a 65 – 600 mm range Microsonic “Cube” Miniature Ultrasonic Proximity Sensor, Push-Pull NO/NC output, IO-Link

cube-35/FFIU

The cube-35/FFIU 65 – 600 mm range Microsonic “Cube” Miniature Ultrasonic Proximity Sensor, 2 x Push-Pull NO/NC output, 1 x analog 4-20mA / 0-10 V, IO-Link

mic+130/D/TC Ultrasonic Proximity Sensor 200 – 2000 mm range, digital display, PNP NO/NC output.

The Microsonic Cylindrical M30 Body mic+130/D/TC is a 200 – 2000 mm range Ultrasonic Proximity Sensor, digital display, PNP NO/NC output.

Features include:

  • 00 – 2,000 mm
  • 1 x PNP NO/NC switching output
  • Operating modes: proximity switch, reflective barrier and window
  • Programming by Teach-in buttons T1 and T2, LinkControl configurable
  • Resolution of 0.18 mm
  • Temperature compensation
  • 9–30 VDC operating voltage
  • Easy mounting M30 nickel-brass housing with M12 – 5 pin connector. IP67 sealing

mic+130/DD/TC Ultrasonic Sensor 200 – 2000 mm range, M30 body, digital display, 2 x PNP NO/NC outputs

The Microsonic Cylindrical M30 Body mic+130/DD/TC is a 200 – 2000 mm range Ultrasonic Proximity Sensor, digital display, 2 x PNP NO/NC outputs.

Features include:

  • 2 x PNP NO/NC switching outputs
  • Operating modes: proximity switch, reflective barrier and window
  • Programming by Teach-in buttons T1 and T2, LinkControl configurable
  • Resolution of 0.18 mm
  • Temperature compensation
  • 9–30 VDC operating voltage
  • Easy mounting M30 nickel-brass housing with M12 – 5 pin connector. IP67 sealing

mic+130/DIU/TC Ultrasonic distance measurement sensor, 200 – 2000 mm range, digital display, analog 4-20 mA, 0-10 V, and PNP NO/NC outputs

The Microsonic Cylindrical M30 Body mic+130/DIU/TC is a 200 – 2000 mm range Ultrasonic Distance Measurement Sensor, with a digital display, analog 4-20 mA, 0-10V, and 1 x PNP NO/NC outputs.

Features include:

  • 0 – 2000 mm
  • Analogue 4-20 mA and 0-10V output
  • Digital PNP NO/NC output
  • Simple programming via a Teach-in buttons T1 and T2 and the digital display
  • Resolution of 0.18 mm to 0.57 mm, depending on the analogue window
  • Temperature compensation
  • 9–30 VDC operating voltage
  • Easy mounting M30 nickel-plated brass housing with M12 – 5 pin connector. IP67 sealing

mic+130/IU/TC Ultrasonic distance measurement sensor, 200 – 2000 mm range, digital display, 4-20 mA and 0-10 V outputs

The Microsonic mic+130/IU/TC is a 200 – 2000 mm range Ultrasonic Distance Measurement Sensor with a digital display, analogue 4-20 mA and 0-10V outputs in an M30 body.

Features include:

  • 0 – 2000 mm
  • Analogue 4-20 mA and 0-10V output
  • Simple programming via a Teach-in buttons T1 and T2 and the digital display
  • Resolution of 0.18 mm to 0.57 mm, depending on the analogue window
  • Temperature compensation
  • 9–30 VDC operating voltage
  • Easy mounting M30 nickel-plated brass housing with M12 – 5 pin connector. IP67 sealing

Microsonic Chemical-Resistant Body crm+130/DD/TC/E is a 200 – 2000 mm range Ultrasonic Proximity Sensor, stainless steel, digital display, 2 x PNP outputs

The Microsonic crm+130/DD/TC/E is a 200 – 2000 mm range Ultrasonic Proximity Sensor.

It features a chemical-resistant stainless steel M30 body with a protective PEEK film layer on the sensing face, digital display, 2 x PNP NO/NC output, and M12 – 5 pin connector.

Operating information is displayed on the built-in digital display and sensor signals are supplied through a single programmable com input.
